بيت مبرد الجرافيت

مبرد تخفيف حمض الكبريتيك من الجرافيت HCL

مبرد تخفيف حمض الكبريتيك من الجرافيت HCL

A Graphite Sulfuric Acid Dilution Cooler is a specialized device designed for the safe dilution of sulfuric acid and the subsequent cooling of the resultant mixture. This ensures that the chemical processing is carried out in an efficient and controlled manner.

  • قسط:

    TT L/C PayPal Westunion Moneygram
  • أصل المنتج:

    China, Anhui province
  • منفذ الشحن:

    Shanghai
  • مهلة:

    1 Month
  • مو:

    1
  • طَرد:

    Wooden case
  • لون:

    Customzied
  • مادة:

    Graphite
  • درجة حرارة العمل:

    165℃
  • ضغط العمل:

    Vertical≤0.1Mpa,Horizontal≤0.4Mpa



Product review

The graphite sulfuric acid dilution cooler is capable of diluting 98% concentrated sulfuric acid to a concentration of 50 - 60% and can also cool the diluted solution to the desired temperature within the same device.



Product advantages



The Graphite Sulfuric Acid Dilution Cooler offers a plethora of advantages. It exhibits high heat transfer efficiency, ensuring effective heat exchange during the dilution and cooling processes. Its excellent corrosion resistance makes it highly suitable for handling the corrosive nature of sulfuric acid, thereby enhancing its durability. The cooler operates reliably, minimizing the risk of malfunctions and ensuring consistent performance.



It achieves uniform dilution of the sulfuric acid, resulting in a homogeneous mixture. Simultaneously, it provides good temperature control, allowing for precise regulation of the cooling process to reach the desired temperature. With a long service life, this cooler can endure extended periods of operation without significant degradation.



The maintenance cost associated with the Graphite Sulfuric Acid Dilution Cooler is relatively low, reducing operational expenses over time. Its compact structure makes it space-efficient and convenient for various installation settings. Moreover, it is easy to install, saving both time and effort during setup.



Notably, this cooler is capable of handling large volumes of sulfuric acid stably, making it an ideal choice for industrial applications where large-scale dilution and cooling are required.



Structural diagram



Parts details
1 Concentrated acid inlet
2 Dilution water inlet
3 Upper cover plate of equipment
4 Graphite upper head
5 Cooling water outlet
6 Graphite mixing chamber cylinder
7 Graphite mixing outdoor cylinder
8 Cooling water inlet
9 Graphite sieve plate
10 Cooling water outlet
11 Vent
12 Equipment support
13 Shell
14 Graphite heat exchange block
15 Drain port
16 Cooling water inlet
17 Graphite lower head
18 Lower cover plate of equipment





Others
