ماص فيلم ساقط من الجرافيت ذو فتحة دائرية

ماص فيلم ساقط من الجرافيت ذو فتحة دائرية

The round block hole graphite falling film absorber efficiently cools and absorbs gases using a vertical, corrosion-resistant graphite structure with uniform liquid distribution.

  • قسط:

    TT L/C PayPal Westunion Moneygram
  • أصل المنتج:

    China, Anhui province
  • منفذ الشحن:

    Shanghai
  • مهلة:

    1 Month
  • مو:

    1
  • طَرد:

    Wooden case
  • لون:

    Customzied
  • مادة:

    Graphite
  • درجة حرارة العمل:

    ≤170℃
  • ضغط العمل:

    Vertical≤0.1Mpa,Horizontal≤0.4Mpa



Product review

Its structure and principle bear resemblance to those of tubular graphite falling film absorbers. Besides possessing the same characteristics as the tube-type graphite falling film absorber, it also offers the advantages of high structural strength, excellent heat shock resistance, high heat transfer efficiency, and convenient maintenance. It is a gas absorption equipment with outstanding performance.





Product advantages

The Round Block Hole Graphite Falling Film Absorber features high heat transfer efficiency, outstanding chemical corrosion resistance, good mechanical strength, uniform fluid distribution, large processing capacity, stable operation, easy maintenance, and a long service life.





Structural diagram



Parts details
1 Air inlet
2 Graphite gas-liquid mixing chamber
3 Liquid inlet
4 Graphite pressure stabilizing ring
5 Graphite distribution head
6 Vent
7 Cooling water outlet
8 Equipment support
9 Graphite heat exchange block
10 Cooling water inlet
11 Drain port
12 Gas liquid separation chamber
13 Tail gas outlet
14 Acid outlet



Drawing Specification Table for Tube
Model Specifications
a.e Tube b.c Tube
DN
f.g Tube
DN
d Tube h Tube
D1 D2 D3 D4 D5 D6
YKX30 5 50 145 50 20 100 210 65 160
YKX40 10 65 160 50 20 150 295 75 180
YKX50 12 75 180 65 20 200 350 100 210
15
YKX60 20 100 210 80 20 250 400 125 240
25

Others
